981 Series: Bevel Sideflexing Chain
Pitch: 1.5″ (38.1mm)
Thickness: 3mm (0.118″)
Hinge: 43mm (1.693″)
Reduced Plate Gap
Contact Us For Price & Availability…
| Material | Width (mm) | Width (inch) | Surface Finish (RA) | Polished Hinges | Yield Load Average (N) | Yield Load Average (lbs) | Weight (kg/m) | Weight (lbs/ft) |
| PRIMA | 82.6 | 3.25 | 0.3 | NO | 8000 | 1798 | 2.74 | 1.84 |
| PRIMA | 83.8 | 3.30 | 0.3 | NO | 8000 | 1798 | 2.77 | 1.86 |
| PRIMA | 114.3 | 4.50 | 0.3 | NO | 8000 | 1798 | 3.38 | 2.27 |
| PRIMA | 190.5 | 7.50 | 0.3 | NO | 8000 | 1798 | 4.82 | 3.24 |
Please Note: Part Numbers can be found within the Regina Technical Datasheet.
| Material | Width (mm) | Width (inch) | Surface Finish (RA) | Polished Hinges | Yield Load Average (N) | Yield Load Average (lbs) | Weight (kg/m) | Weight (lbs/ft) |
| PRIMA | 82.6 | 3.25 | 0.3 | NO | 8500 | 1913 | 2.00 | 1.34 |
| PRIMA | 83.8 | 3.30 | 0.3 | NO | 8500 | 1913 | 2.14 | 1.44 |
| PRIMA | 114.3 | 4.50 | 0.3 | NO | 8500 | 1913 | 2.21 | 1.49 |
| PRIMA | 190.5 | 7.50 | 0.3 | NO | 8500 | 1913 | 2.57 | 1.72 |
Please Note: Part Numbers can be found within the Regina Technical Datasheet.
 | PRIMA – Superior Grade Ferritic Stainless Steel | Superior grade of cold rolled special ferritic stainless steel. Special alloys offer very good wear and mechanical properties. Particularly suitable for high productivity lines. |
 | Austenitic Stainless Steel (PIN MATERIAL) | Austenitic stainless steel guarrentees excellent corrosion resistance to withstand chemical. Very good wear resistance. |
Sprockets For 981 Series Belt
Available: Moulded/Machined, Drive/Idle, Multiple Bore Sizes & Various Teeth Quantities.
